The Liftmaster TOP LIFT 2.50 TLK is a German-manufactured in-ground electro-hydraulic lift designed to accommodate larger vehicles and commercial vans with ease. With a lifting capacity of 5,000 kg and arm reach of 850–1,750 mm, it offers excellent flexibility and coverage for a wide range of wheelbases and lifting points.
This lift is built with dual hydraulic pistons housed in a powder-coated canister that contains a fully integrated lifting and power unit. The cassette design allows easy access to internal components via a removable cover, making servicing simple and efficient.
The hydraulic cylinders are protected within Ø123 mm hard-chromed guide pipes, which are securely mounted to a galvanised traverse to ensure synchronised movement and non-rotating operation of the lift runways.
Ideal for high-demand workshops requiring power, durability, and low-profile installation, the TLK 2.50 delivers uncompromising performance.
Key Features:
-
Lifting Capacity: 5,000 kg
-
Arm Reach: 850 mm – 1,750 mm
-
Dual Hydraulic Pistons for even, controlled lifting
-
Integrated Power and Lifting Unit pre-installed in the cassette
-
Hard-Chromed Ø123 mm Guide Pipes for durability
-
Galvanised Traverse – ensures synchronised and stable lifting
-
Powder-Coated Cassette with removable cover for easy maintenance
-
Power Supply: 3 Phase, 440 V, Neutral & Earth, 16 A (C or D-rated) breaker
-
Engineered in Germany for professional-grade reliability
Technical Specifications:
-
Lift Capacity: 5,000 kg
-
Lifting Arm Range: 850 mm – 1,750 mm
-
Lift Type:Â In-ground, dual-piston
-
Cassette:Â Powder coated with integrated hydraulic and power unit
-
Guide Pipes: Ø123 mm, hard-chromed
-
Traverse:Â Galvanised, anti-rotation
-
Power Requirement: 3 Phase, 440 V, Neutral & Earth, 16 A (C or D-rated) breaker
